- Dual Monitoring: The NDM-100 is equipped to monitor and supervise two separate two-wire initiating device circuits, providing comprehensive coverage for fire detection and supervisory devices.
- Automatic Address Assignment: This module automatically assigns itself to two consecutive addresses within the intelligent system, streamlining the installation process and ensuring efficient address allocation. For instance, if the module is set to address "26," it will automatically assign itself to addresses "26" and "27."
- Compact Design: With a standard-sized form factor, the NDM-100 module can be seamlessly integrated into existing systems. It mounts directly to a standard 4" square, 2.125" deep electrical box or the SMB500 surface-mount box, offering flexibility in installation options.
- LED Status Indicator: The module features a single panel-controlled LED, providing visual indication of its operational status. This LED serves as a convenient diagnostic tool for system maintenance and troubleshooting.
- Normal Operating Voltage Range: The NDM-100 operates within a voltage range of 15 to 32 VDC, ensuring compatibility with standard power sources in fire alarm systems.
The Notifier NDM-100 is a standard-sized dual monitor module designed to monitor and supervise two independent two-wire Style B (Class B) dry-contact initiating device circuits (IDCs) simultaneously. This advanced module is specifically engineered for integration into intelligent, two-wire systems, offering reliable monitoring capabilities for fire alarm and supervisory devices.
